SFP Media converter

General Description

950SFP series converter is an Ethernet media converter that converts media transmission between UTP Copper cables and fiber SFP (Small Form-Factor Pluggable) transceiver. It is designed to meet the massive needs for Ethernet network deployment and able to extend a copper based network via fiber cable to a maximum distance up to 120km. It can be installed into a Standard Converter Chassis. The installation & operation procedures are simple & straight forward. Operation status can be locally monitored through a set of Diagnostic LED located in the front panel

Features

* 100Base-TX/FX or 1000Base-T to 1000BASE-SX/LX Converter
* Standard : IEEE802.3 & IEE802.3u, IEEE 802.3z & 802.3ab
* Interface: 1 x RJ-45 connector / 1 x SFP Slot
* Plug-and-Play installation
* Support Jumbo Frame (64-9216 Byte)

* Conversion between different transmission speeds and media types

* Standalone type or card type ,Can be installed into 2U 14/16Slots chassis

* Auto-negotiating Ethernet port (Half/Full Duplex)

* Auto-crossover Ethernet port (Supports Auto MDI/MDI-X)

* Easy Installation, Easy Trouble shooting

* Dimension: 229x122x50mm for packing, 94x70.6x26.5mm for device

Application

* Extend your Ethernet connection up to 0~120km away using fiber optics.

* Creates an economical Ethernet-fiber/copper-fiber link for connecting remote sub-networks to larger fiber optic networks/backbones.

* Converts Ethernet to fiber, fiber to copper/Ethernet, ensuring optimum network scalability for connecting two or more Ethernet network nodes (e.g. connecting two buildings on the same campus).

* Designed to provide high-speed bandwidth for demanding large scale work groups that require expansion of Ethernet Network.

* Bad industrial environment or high requirements for Lightning protection
* Intelligent transportation supervisory system(ITS) and safe cit

* High-speed way supervisory/Tele-communication system, IP network camera
* Security surveillance system for large corporations, multifunction network system
* Long-distance multimedia schooling/ campus surveillance, long-distance broadcast television transmission system

OEM and ODM

OEM and ODM order is optional.
We provide SPM-EV14T453-N20S according to your requirements, and customize packaging with SM 20KM SC 10/100M fiber media converter label and your logo

Shipment
International Express: DHL, FedEx, UPS, TNT and EMS
Shipments are usually delivered in 1-3 working days after received payment and 1-3 days after received the PO for the VIP customers.
Guangtong is your reliable supplier of SPM-EV14T453-N20S 10/100M Ethernet 1550nm/1310nm single mode fiber media converter/switch with 4UTP ports SM single fiber 20km with Vlan SC connector external power supply. We test each piece of smart media converter/switch before shipment to ensure the SPM-EV14T453-N20S 10/100M Ethernet 1550nm/1310nm single mode fiber media converter/switch with 4UTP ports SM single fiber 20km with Vlan SC connector external power supply can work in your system without any problems.
