16 CH Balanced Audio

Classification：音频光端机
Time：2021/6/7 20:47:36
View：993

Details

16 CH Balanced Audio(XLR)To Fiber Optic support 16 Channel balanced audio 16-bit digitally encoded broadcast quality balanced audio over one multi-mode or single-mode optical fiber. These fiber optic transmitter and fiber optic receiver are typically used in applications for Rental, Staging, Theater, Stadiums, Theme Parks, Broadcast/Studio, CCTV audio and Professional AV applications, etc, and are available for stand-alone or rack-mount installations. FC, ST or SC optical connectors is optional.

Plug and Play design ensures adjustment-free installation and operation, and optical adjustments are never required. LED indicators are provided to instantly monitor the system operating status.

Specifications

Wavelength	1310nm&1470nm~1610nm
Output Power	-9~ -3dBm / -5~0dBm
Optic fiber	50/125u multimode，62.5/125u multimode，9/125u single mode
Rx sensitivity	-25dBm
Optical connector	FC /ST /SC /LC (optional)
Distance	0~500M (MM) / 0~20KM/40KM/60KM/80KM (SM)

删除列

删除行

插入列

插入行

向右合并单元格

向下合并单元格

水平拆分单元格

垂直拆分单元格

背景色

删除表格

全选表格

隐藏边框

Balanced Audio

Number of Channels	16
Input Connector	XLR（female）
Output Connector	XLR（male）
Input / Output Impedance	10K Ohm
Input capacitance LINE inputs	10 pF
Max input/output voltage	1.0Vp-p
Frequency Response	20 Hz～24kHz @±3dB
Sample Rates From	48kHz
SNR	> 80dB

删除列

删除行

插入列

插入行

向右合并单元格

向下合并单元格

水平拆分单元格

垂直拆分单元格

背景色

删除表格

全选表格

隐藏边框

Electrical & Mechanical

Power Adapter:	AC 90V~240V
Power Consumption:	< 8W
Installation	19’’ 1U rack-mount chassis
Shipping Weight:	(include Transmitter & Receiver ) 7kg

删除列

删除行

插入列

插入行

向右合并单元格

向下合并单元格

水平拆分单元格

垂直拆分单元格

背景色

删除表格

全选表格

隐藏边框

Environmental

Operating Temperature:	-20°C ~ +75°C
Storage Temperature:	-40°C ~ +85°C
Relative Humidity:	0% ~ 95% (non-condensing)
MTBF:	>100,000 hours

删除列

删除行

插入列

插入行

向右合并单元格

向下合并单元格

水平拆分单元格

垂直拆分单元格

背景色

删除表格

全选表格

隐藏边框

Packing list

1 Pair (Transmitter & Receiver) 2 x Power supply 1 x User manual
